Structure Fittings Unequal Bracket

Home › Products › Structure Fittings Unequal Bracket

‹ › ⚲

1 / 4

× ‹ ›

Structure Fittings Unequal Bracket

Our Unequal Bracket Fittings (UBT Series) are precision-engineered to provide offset or asymmetric right-angle connections between tubes of different nominal bores or dimensions, allowing flexibility in structural layouts where equal brackets are not suitable. These fittings slide onto matching galvanized tubes and are secured with grub screws, enabling modular assembly without welding.

Ideal for glass plant support structures, industrial frameworks, and laboratory installations, unequal brackets provide rigid orthogonal junctions while accommodating dimensional offsets, supporting lateral loads, torsional stability, and design flexibility.

Key Highlights:

• Offset Right-Angle Connections – Enables unequal branch placement in support frames
• Modular & Adjustable Design – Slide-on installation with grub screw locking
• Durable Materials – Cast iron standard; stainless steel 304/316 optional
• Standardized Catalog Models – UBT25, UBT30, UBT40, UBT50 for NB 25mm to 50mm
• Supports Lateral & Torsional Loads – Maintains structural integrity in asymmetric designs

How Unequal Bracket Fittings Work: Step-by-Step Process

1. Select the Correct Model – Match NB (nominal bore) of each tube with the fitting.
2. Slide Bracket onto Main Tube – Ensure full engagement along the primary h and L dimensions.
3. Align Offset Tube – Fit the branch tube at 90° with required offset distance for design needs.
4. Secure with Grub Screws – Lock both tubes in place for rigid, stable connection.
5. Check Load & Clearance – Verify that offset alignment does not interfere with other structural components.
6. Install Bracing if Needed – Support high-load or asymmetric sections to maintain rigidity.

Key Features & Benefits

• Offset or Unequal Branch Support – Ideal for non-symmetrical structural layouts
• Modular & Adjustable – Allows future reconfiguration without welding
• High-Strength & Durable Materials – Cast iron or stainless steel options
• Full Engagement Geometry – Maintains stability along primary and offset lengths
• Supports Lateral & Torsional Loads – Prevents twisting or uneven stress in frames
• Corrosion-Resistant Options – Stainless steel variants suitable for harsh environments

Technical Specifications: Unequal Bracket Models & Dimensions

Material & Construction Notes:

• Slidable design with grub screws ensures secure tube engagement
• Offset (L1) dimension provides clearance for asymmetrical layouts
• Optional stainless steel 304/316 for corrosive or wet environments
• Bracket geometry ensures rigidity and torsional stability in asymmetric configurations

Industries We Serve

• Industrial Manufacturing – Asymmetric structural frames for machinery
• Laboratory & Research Facilities – Support structures for glass pipelines with offset tubes
• Construction & Engineering – Lattice frameworks requiring unequal branch placement
• Chemical & Pharmaceutical Plants – Corrosion-resistant supports for pipelines and equipment
• Pilot Plants & Educational Facilities – Demonstration setups requiring modular offset connections

Why Choose Our Unequal Bracket Fittings?

• Premium Cast Iron & Stainless Steel – Long-lasting, corrosion-resistant, and reliable
• Precision Engineering – Accurate NB sizing and offset alignment
• Modular & Flexible – Supports future structural reconfiguration without welding
• Fast Worldwide Shipping & Bulk Orders – Save with volume discounts
• Industrial-Grade Reliability – Maintains rigid support in asymmetric frame layouts

Applications of Unequal Bracket Fittings

• Provide offset right-angle connections in modular frameworks
• Support lateral and torsional loads in asymmetric structures
• Build rigid junctions where equal brackets cannot fit
• Enable modular reconfiguration in industrial or laboratory settings
• Maintain alignment and stability in offset or non-symmetrical layouts

Order Your Unequal Bracket Fittings Today!

• In Stock – Limited Availability!

• Bulk Discounts Available – Save More on Large Orders!

• Customizable & Scalable – Designed for asymmetric structural layouts

• Ships Worldwide – Fast & Reliable Delivery!

Contact us today to get a custom modular support solution for offset and asymmetric frame designs!

Frequently Asked Questions (FAQs)

Q1: What materials are Unequal Bracket Fittings made of?
A: Standard cast iron, optional stainless steel 304/316 for corrosive environments.

Q2: Can these brackets handle offset loads?
A: Yes, designed for lateral and torsional stability in asymmetric layouts.

Q3: Are Unequal Brackets modular?
A: Yes, slide-on design with grub screws allows modular assembly and adjustments.

Q4: Do they require welding?
A: No welding is needed; secure using grub screws.

Q5: Are bulk orders available?
A: Yes, we offer bulk discounts and worldwide shipping.
