Structure Fittings Equal Bracket

Home › Products › Structure Fittings Equal Bracket

‹ › ⚲

1 / 4

× ‹ ›

Structure Fittings Equal Bracket

Our Equal Bracket Fittings (EBT Series) are engineered to provide rigid right-angle connections between tubes of the same nominal bore, forming a balanced orthogonal support in structural frameworks. These brackets slide onto matching galvanized tubes and are secured with grub screws, enabling modular assembly without welding or heavy fabrication.

Ideal for glass plant support structures, industrial frameworks, and laboratory pipelines, equal brackets offer stability, load-bearing capacity, and flexibility for future modifications.

Key Highlights:

• Right-Angle Tube Connections – Ensures orthogonal junctions in frame systems
• Modular & Adjustable Design – Slide-on fit with grub screw locking
• Durable Materials – Cast iron standard, stainless steel 304/316 optional
• Standardized Catalog Models – EBT25, EBT30, EBT40, EBT50 for NB 25mm to 50mm
• Supports Lateral Loads – Maintains alignment and structural integrity

How Equal Bracket Fittings Work: Step-by-Step Process

1. Select the Correct Model – Match NB (nominal bore) with your tubing.
2. Slide Bracket onto Tube – Insert tube into internal bore for full engagement along h and L dimensions.
3. Align Perpendicular Tube – Fit the second tube at 90° to form orthogonal junction.
4. Secure with Grub Screws – Tighten screws to lock bracket in place.
5. Check Rigidity & Load Distribution – Ensure no twisting or uneven stress along the frame.
6. Install Additional Bracing if Needed – Support high-load sections for maximum stability.

Key Features & Benefits

• Balanced Orthogonal Support – Ideal for structural grids, frames, and glass plant supports
• Modular & Adjustable – Allows future reconfiguration without welding
• High-Strength Materials – Cast iron or stainless steel for long-term durability
• Precise Bracket Geometry – Full engagement along h and L for stable connection
• Supports Lateral Loads – Maintains alignment and prevents structural twisting
• Corrosion-Resistant Options – Stainless steel variants for harsh chemical environments

Technical Specifications: Equal Bracket Models & Dimensions

Material & Construction Notes:

• Slidable design with grub screws ensures secure engagement
• L1 dimension provides necessary offset or clearance for design flexibility
• Stainless steel 304/316 options available for corrosive or wet environments
• Full engagement along h and L ensures maximum structural rigidity

Industries We Serve

• Industrial Manufacturing – Modular support frameworks for machinery
• Laboratory & Research Facilities – Structural support for glass pipelines
• Construction & Engineering – Lattice and grid frameworks
• Chemical & Pharmaceutical Plants – Corrosion-resistant support for piping and equipment
• Pilot Plants & Educational Facilities – Demonstration setups requiring rigid orthogonal junction

Why Choose Our Equal Bracket Fittings?

• High-Quality Cast Iron & Stainless Steel – Long-lasting and reliable
• Precision Engineering – Ensures orthogonal alignment and rigidity
• Modular & Flexible Design – Supports future modifications without welding
• Fast Worldwide Shipping & Bulk Orders – Save with volume discounts
• Industrial-Grade Reliability – Maintains load-bearing capacity under lateral stress

Applications of Equal Bracket Fittings

• Form right-angle connections in support grids and modular frames
• Support lateral and perpendicular loads in industrial and laboratory structures
• Build rigid orthogonal junctions in glass plant infrastructures
• Enable modular reconfiguration of structural frameworks
• Maintain structural alignment and prevent twisting or bending

Order Your Equal Bracket Fittings Today!

• In Stock – Limited Availability!

• Bulk Discounts Available – Save More on Large Orders!

• Customizable & Scalable – Tailored for your structural needs

• Ships Worldwide – Fast & Reliable Delivery!

Contact us today to get a custom modular support solution for your structural framework!

Frequently Asked Questions (FAQs)

Q1: What materials are Equal Bracket Fittings made of?
A: Standard cast iron, optional stainless steel 304/316 for corrosive environments.

Q2: Can Equal Brackets handle lateral loads?
A: Yes, designed to maintain orthogonal alignment and structural integrity under lateral stress.

Q3: Are these brackets modular?
A: Yes, slide-on design with grub screws allows modular assembly and adjustments.

Q4: Do they require welding for installation?
A: No welding is needed; secure using grub screws.

Q5: Are bulk orders available?
A: Yes, we provide bulk discounts and worldwide shipping.
