Glass Lined Reactor Assembly

The Glass Lined Reactor Assembly with Glass Cover is a high-performance industrial reaction system engineered for scaling laboratory processes to pilot and production levels while closely replicating actual production conditions. Comparable to AGR-type distillation reactor assemblies, this system integrates reaction, distillation, and process monitoring into a single robust setup.

By combining a steel outer shell with a chemically inert glass lining, the reactor delivers exceptional corrosion resistance, product purity, and mechanical strength, making it ideal for pharmaceutical, fine chemical, and specialty chemical manufacturing.

Material Considerations – Why Glass Lined Construction?

Selecting the correct construction material is critical for processes involving corrosive chemicals, high purity requirements, or aggressive reaction conditions.

Glass & Glass Linings are preferred due to:

• Non-reactive and contamination-free surface
• High resistance to acids, alkalis, and solvents
• Smooth, non-stick interior for easy cleaning
• Long service life in harsh environments

The glass-lined steel design merges the best of both materials:

• Steel → mechanical strength & pressure capability
• Glass lining → corrosion resistance & product purity

Working Principle – How the Glass Lined Reactor Assembly Operates

1. Raw materials are charged into the glass-lined reaction vessel
2. Controlled heating or cooling is applied through the jacket
3. Glass-lined steel stirrer ensures uniform mixing without contamination
4. Vapors generated during reaction are routed to the integrated distillation system
5. Condensate is collected via twin distillate receivers for continuous operation
6. Reaction parameters are monitored using PT100 temperature sensors (optional)

This design ensures high batch consistency, safety, and scalability.

Technical Specifications

Safety & Operating Advantages

•  Zero metal contamination due to glass-lined contact parts
•  Excellent pressure & temperature resistance
•  Cryogenic operation capability up to -60°C
•  Stable mechanical construction
•  Safe handling of corrosive media
•  Improved heat transfer efficiency
•  CIP system reduces manual cleaning risks

Designed for continuous, safe, and reliable industrial operation.

 Key Features & Benefits

• Glass-lined steel construction for purity & durability
• Transparent glass cover for real-time process observation
• Twin receiver system for uninterrupted distillation
• Integrated baffles for enhanced mixing efficiency
• Excellent heat addition & removal for precise batch control
• Scalable design from pilot to production scale

Optional Accessories & Customization

(Standardized across reactor systems – Add / Remove / Mix & Match)

• Jacketed heating & cooling system
• Oil circulation unit / Chiller integration
• Vacuum system with condenser
• Reflux divider & fractionation column
• Automated temperature & pressure control
• Sampling valves
• Load cell based weighing system
• PLC / SCADA automation
• Custom nozzle & port configuration

Customization available based on process chemistry and capacity.

Industries We Serve

 Pharmaceutical Industry

• API manufacturing
• Intermediate production
• High-purity reactions
• Cryogenic synthesis
• Process scale-up

 Chemical & Fine Chemical Industry

• Corrosive chemical processing
• Specialty chemicals
• Batch reaction systems
• Controlled distillation processes

 Research & Pilot Plants

• Process development
• Scale-up validation
• Reaction optimization
• Technology transfer to production

Advantages of Glass Lined Reactor with Glass Cover

The glass-lined steel construction offers unmatched operational advantages:

•  Steel exterior provides mechanical robustness
•  Glass lining ensures chemical inertness & purity
•  Handles high temperatures & pressures
•  Resistant to acidic & alkaline media
•  Supports cryogenic reactions
• Efficient heat transfer for accurate batch control

Frequently Asked Questions (FAQs)

Q1. What capacity range is available?
From 63 Liters up to 1 KL.

Q2. Can it handle corrosive chemicals?
Yes, the glass lining provides excellent corrosion resistance.

Q3. Is cryogenic operation supported?
Yes, the reactor supports temperatures down to -60°C.

Q4. Can distillation be performed simultaneously?
Yes, with integrated distillation system & twin receivers.

Q5. Is automation possible?
Yes, PLC/SCADA automation can be integrated.

Why Choose Our Glass Lined Reactor Assembly?

• Production-grade design
• High purity & contamination-free processing
• Excellent safety & reliability
• Scalable from pilot to industrial scale
• Custom-engineered solutions
• Proven performance in demanding industries
