Jacketed Pipe Sections

Jacketed Pipe Sections

Bhanu Scientific Glass Co. offers premium jacketed glass pipe sections designed for controlled heating or cooling of process fluids. These dual-wall pipeline components are ideal for chemical, pharmaceutical, and pilot plant operations requiring precise temperature regulation.

Jacketed pipe sections are pipeline segments encased in an outer jacket, allowing thermal fluids (steam, oil, or water) to circulate around the inner pipe. This enables precise temperature control of the process fluid without exposing it to direct heating or cooling.

Key Features:

• Material: Borosilicate glass 3.3 for the inner pipe; outer jacket made of glass or compatible material
• Dual-Wall Design: Separate inner flow and outer jacket channels
• Nominal Diameters (DN): Standard DN 15–800, custom sizes available
• Temperature Control: Jacket allows steam, hot/cold water, or thermal oil circulation
• Pressure & Vacuum Compatibility: Suitable for industrial vacuum or mild positive pressures
• Smooth Surface Finish: Minimizes fouling, ensures easy cleaning
• Custom Options: Length, port locations, jacket inlet/outlet positions per requirement

Applications

• Temperature-sensitive chemical reactions
• Solvent or media transfer in controlled temperature pipelines
• Distillation, extraction, and filtration lines
• Biopharmaceutical and food processing lines
• Pilot and research plant setups requiring thermal regulation

Benefits

• Precise Thermal Control: Outer jacket provides stable heating or cooling
• Chemical Inertness: Borosilicate glass ensures corrosion resistance
• Easy Cleaning & Maintenance: Smooth surfaces prevent fouling
• Visual Monitoring: Transparent inner pipe for observing flow and reactions
• Customizable Design: Length, diameter, and port placement tailored to process needs

Industries We Serve

• Chemical & Petrochemical
• Pharmaceutical & Biotech
• Food & Beverage
• Research & Development Laboratories
• Pilot Plant and Industrial Process Systems

Why Choose Our Jacketed Pipe Sections?

• High-Quality Borosilicate Glass: Maximum chemical and thermal resistance
• Dual-Wall Jacket Construction: Precise and safe thermal management
• Vacuum and Pressure Rated: For reliable industrial operation
• Customizable Solutions: Designed to meet your exact process requirements
• Optional Accessories: Clamps, PTFE gaskets, temperature sensors, mounting frames

FAQs

Q: Can the jacket handle steam or oil for heating?
A: Yes, the outer jacket can circulate steam, hot water, or thermal oil for controlled heating.

Q: Are these pipes vacuum-compatible?
A: Yes, designed for full vacuum and low-pressure operations.

Q: Can we customize the pipe length and port positions?
A: Absolutely, all dimensions and port placements are customizable.

Q: Can jacketed pipes be integrated into existing glass pipeline systems?
A: Yes, fully compatible with standard borosilicate glass pipeline fittings and components.
