Gas Scrubber

Gas Scrubber

The Gas Scrubber is a high-efficiency glass gas purification system designed for laboratory, pilot, and small-scale industrial applications. It safely removes acidic, basic, or odorous gases, vapors, and particulates from exhaust streams using absorption, neutralization, or chemical scrubbing techniques. Constructed with borosilicate glass 3.3, the unit provides complete visibility of gas-liquid interaction, allowing operators to monitor the process for optimal efficiency.

Key Features & Benefits

•  Efficient Gas Cleaning: Removes acidic, basic, or toxic gases from exhaust streams
•  High Chemical Resistance: Borosilicate glass 3.3 with PTFE/SS supports
•  Various Scrubbing Media Support: Water, alkaline, or acidic solutions
•  Modular & Compact: Easy integration into lab or pilot setups
•  Visual Monitoring: Transparent design allows observation of scrubbing efficiency
•  Versatile Applications: Environmental compliance, pilot plant studies, R&D

How Does It Work?

• Contaminated gas enters the scrubber column.
• Gas is contacted with scrubbing media via packed bed, spray tower, or venturi configuration.
• Pollutants dissolve or neutralize in the liquid phase.
• Clean gas exits the top of the column, while spent liquid collects in the bottom vessel.
• Optional recirculation and monitoring systems enhance efficiency and control.

Technical Specifications

Parameter	Specification
Vessel Capacity	5 L – 200 L
Column Diameter	50 mm – 300 mm
Construction Materials	Borosilicate Glass 3.3, PTFE, Stainless Steel Frame
Operating Temperature	Up to 120 °C
Gas Flow Range	10 – 500 m³/hr (depending on model)
Operating Pressure	Atmospheric / Low Pressure
Scrubber Types	Packed Bed, Spray Tower, Venturi Configuration
Optional Accessories	Recirculation Pump, pH Monitor, Mist Eliminator, Sampling Ports
Applications	Lab exhaust, pilot-plant gas purification, emission compliance studies
Observation	Transparent glass for visual monitoring of gas-liquid contact

Industries & Applications

• Pharmaceutical & Chemical Industries – Laboratory exhaust, off-gas scrubbing
• Environmental & Safety – Emission control, neutralization of toxic gases
• Research & Development Labs – Pilot plant studies, process development
• Educational Demonstrations – Chemical engineering and gas treatment teaching

Why Choose Our Gas Scrubber?

•  Safe & Contained Operations: Closed system prevents operator exposure
•  Customizable Scrubber Media & Configuration for specific gas streams
•  Visual Process Monitoring through transparent borosilicate glass
•  Long-Lasting & Corrosion-Resistant materials ensure durability
•  Compact & Modular design for integration into lab or pilot-scale setups

Optional Accessories & Customization

• Recirculation pump for continuous liquid flow
• pH and temperature monitoring sensors
• Mist eliminators to prevent liquid carryover
• Additional sampling ports and drain valves
• Integration with downstream filtration or distillation units
