Bends 45 Degrees

Bends 45 Degrees

Bhanu Scientific Glass Co. offers precision-engineered 45° glass bends for industrial and laboratory piping systems. These bends provide gentle directional change, reducing turbulence while maintaining chemical resistance, transparency, and structural stability.

45° bends are ideal for smooth directional adjustments in pipelines, minimizing pressure loss and optimizing flow dynamics. Made from borosilicate glass 3.3, these bends are perfect for vacuum and low-pressure applications while offering high visibility of fluid flow.

Key Applications:

• Distillation, extraction, and chemical process pipelines
• Laboratory and pilot-scale systems
• Integration points for sampling, instrumentation, or branch lines

Here’s a technical specification table for Bends 45° in your glass pipeline section:

Parameter	Specification / Range
Material	Borosilicate Glass 3.3
Bend Angle	45° ± tolerance
Nominal Diameter (DN)	15 – 800 (custom DN 1000 available)
Pressure Rating	Low to moderate positive pressure
Vacuum Rating	Full vacuum compatible
Surface Finish	Smooth interior for minimal pressure drop and fouling
Temperature Range	Typical process limits for borosilicate glass (up to ~200°C)
Optional Ports	Thermometer branch, side outlet, bottom outlet
Length (L)	Based on DN and process layout (customizable)
Flange / Connection	Standard glass flanges or clamp connections
Corrosion Resistance	Compatible with acids, solvents, and aggressive chemicals
Customization	Custom DN, lengths, ports, or integration with instrumentation
Visual Monitoring	Fully transparent for observing fluid flow

If you want, I can also create a combined table for all bends (10°, 45°, 80°, 90°, U, Y, etc.) for your catalog—it will make it easier for your website or PDF documentation.

Key Features

• High Chemical Resistance – Compatible with acids, solvents, and corrosive media
• Transparent Design – Monitor fluid flow visually
• Vacuum & Pressure Rated – Safe for low-pressure and vacuum processes
• Customizable Ports – Thermometer or sampling ports available
• Durable Construction – Borosilicate glass ensures long-lasting reliability

Applications

• Chemical and pharmaceutical process pipelines
• Laboratory and pilot plant installations
• Distillation, extraction, and solvent circulation lines
• Vacuum or low-pressure fluid handling systems
• Sampling and monitoring points

Benefits

• Smooth directional flow reduces pressure drop
• High corrosion resistance for harsh chemical environments
• Visual monitoring of liquids and reactions
• Customizable for instrumentation and safety
• Reliable, long-lasting performance

Industries We Serve

• Chemical & Petrochemical
• Pharmaceutical & Biotechnology
• Food & Beverage Processing
• Research & Development Laboratories
• Pilot Plants & Industrial Process Facilities

Optional Accessories

• Thermometer branch attachment
• Bottom or side outlet for sampling
• Clamp supports for secure mounting
• Protective jackets for thermal or mechanical protection

FAQs

Q: Can 45° bends be used in vacuum pipelines?
A: Yes, they are fully vacuum-compatible and can also handle low positive pressures.

Q: Can custom ports be added?
A: Yes, side branches or thermometer ports can be added as per your process requirements.

Q: What DN sizes are standard?
A: DN 15–800 standard, with DN 1000 available on request.

Q: Are these bends suitable for aggressive chemicals?
A: Absolutely, borosilicate glass provides excellent chemical resistance.
