Micro Filtration Assembly

Micro Filtration Assembly

The Micro-Filtration Assembly is a laboratory-scale glass filtration module engineered for high-precision separation of fine particulates, colloids, and ultrafine solids from liquids. Built entirely around borosilicate glass 3.3, the assembly ensures excellent chemical compatibility, thermal stability, and full visual monitoring of the filtration process.

The system typically consists of a glass filtration housing, membrane or frit support, feed inlet, permeate outlet, retentate line, and sampling ports. Designed for low-pressure operation, it is ideal for applications where controlled filtration, minimal contamination, and product integrity are critical. The modular construction allows quick disassembly, cleaning, and replacement of filter elements to suit different process needs.

Material & Construction

• Main Body: Borosilicate Glass 3.3
• Wetted Parts: PTFE (chemically inert, solvent-resistant)
• Transparency: Clear glass housing for process observation
• Design: Modular, service-friendly construction

Technical Specifications

• Operating Pressure: Atmospheric to 0.5–1 bar (laboratory scale)
• Operating Temperature: Ambient to ~120–150 °C (solvent dependent)
• Filter Support Options:
• Glass frit
• Ceramic membrane
• Polymer membrane (application-specific)
• Housing Volume: Typically < 1 L
• Connections: Standard glass joints for feed, permeate & retentate
• Flow Rates: Low-volume operation (mL to few L/h)
• Sealing: PTFE gaskets or compatible chemical-resistant seals

Key Features

• Fine particle and colloidal filtration
• Excellent chemical and solvent compatibility
• Low shear, gentle filtration for sensitive samples
• Easy membrane/frit replacement
• Leak-resistant sealing with PTFE components
• Compact design for benchtop laboratory use

Typical Applications

• Clarification of colloidal suspensions
• Filtration of fine precipitates and ultrafine solids
• Sample preparation for analytical testing
• Pharmaceutical and chemical R&D filtration
• Filtration of biological, herbal, or specialty chemical extracts
• Small-batch purification requiring high cleanliness standards

Advantages in Laboratory Use

• High visibility ensures process control and reproducibility
• Modular layout enables quick configuration changes
• Easy cleaning reduces cross-contamination risk
• Precise filtration without disturbing sensitive compounds
• Ideal for method development and scale-down studies

Frequently Asked Questions (FAQ)

Q1. What filtration media can be used in this assembly?
Glass frits, ceramic membranes, or polymer membranes can be selected based on pore size and chemical compatibility.

Q2. Is the assembly suitable for pressure filtration?
It is designed for low-pressure operation up to approximately 1 bar.

Q3. Can it be used with aggressive solvents or acids?
Yes, borosilicate glass and PTFE wetted parts provide excellent resistance to most laboratory chemicals.

Q4. Is customization possible?
Yes, housing size, membrane type, pore size, and port configuration can be customized as per application.
